Why gold mining need thickener in  leaching CIL CIP plant

In gold leaching plant cip / cil , in order to increase the concentration of the slurry,need gold ore thickener, concentrated  slurry will affect the leaching time ,and the suspension state of the activated carbon.

Detail functions:

1.Increase leaching efficiency‌：When the slurry reaches a suitable leaching concentration, the leaching efficiency can be improved.

2. Prevent clogging: The thickener can remove impurities in the slurry, such as sawdust, to prevent these impurities clogging the pipeline and the carbon screen.

3.Reducing energy consumption‌：suitable  slurry concentration can reduce the demand for stirring speed and temperature

Working Steps of gold thickener

Through gravity sedimentation, the solid particles in the slurry are settled to the bottom to achieve solid-liquid separation.

The thickener is usually composed of a tank, a rake frame, a speed reducer, a rake lifting device and a feed trough.

During transmission, the main shaft and the rake frame are driven by a speed reducer motor to rotate at a low speed, and the settled ore particles are scraped and collected to the discharge port , then achieving dehydration and concentration.

Which kind of gold mine suitable for leaching

High leaching rates gold ore suitable for leaching plant, usually these gold mine do not contain or contain small amounts of difficult to process minerals, such as pyrite, magnetite, white iron ore, etc.High leaching rate minerals will not excessively consume gold dressing agent and other chemical reagents , thus ensuring effective extraction.
